Blue Sea E-Series Battery Switch On-Off With AFD

$53.01
Share

Ships Within 1-2 Business Days

Free Shipping On Orders Over $500

Options

$53.01
Or

WARNING ⚠️

You must be 18 or older to purchase shotgun or rifle ammunition and 21 or older to purchase handgun ammunition and firearms. Please reference our requirements for ammunition orders to "restricted" states HERE.  Always make sure you use the correct ammunition for your firearms. Ammo cannot be shipped to a PO Box. Please reference state & local laws before making a firearm or ammunition purchase.

Purchasing a Firearm? Click HERE to see our firearm purchasing guide.

Info

SKU:BSS9004E ,UPC:

SKU: BSS9004E

UPC: 632085900458

MPN: 9004e-BSS

Info

SKU:
BSS9004E
UPC:
632085900458
MPN:
9004e-BSS

Description

Blue Sea Systems e-Series On-Off Battery Switch with AFD

Model: 9004E-BSS
  • 350 Amps continuous rating for inboard gasoline or diesel engines.
  • Tin-plated copper studs for maximum conductivity and corrosion resistance
  • Accepts up to 4/0 AWG battery cables
  • Studs accepts 3/8" (M10) ring terminals
  • 7/8" (22mm) stud length accepts multiple cable terminals
  • Blue Sea Systems one-piece terminal stud design never loosens over time
  • Fits most Perko and Guest low amperage battery switch hole patterns
  • Case design allows surface or rear panel mounting
  • Tactile indicator conveys knob position by feel
  • Waterproof — rated IP66 from water projected in powerful jets
  • Ignition protected—safe for installation aboard gasoline powered boats
  • Includes AFD (Alternator Field Disconnect)

Switches a single battery to a single load group

Specifications
Switch TypeSingle Circuit ON-OFF
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field DisconnectYes
Maximum Voltage48V DC
Terminal Stud Torque140 in-lb (15.82 Nm)
Continuous Rating350A
Intermittent Rating600A (5 min)
Cranking Rating 30 sec1200A per circuit
Battery Inputs1
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm )
Mounting HolesAccept 1/4" (M6) Screw
Stud MaterialTinned Copper
Terminal Stud Size3/8" - 16 (M10)
