Blue Sea HD-Series Battery 4 Position 500A Alternator Field Disconnect

$86.91
Share

Options

$86.91
Or
Ships 1–2 Business Days Fast processing & tracking
Free Shipping $500+ Best value for bulk orders
Easy 60-Day Returns Some exclusions apply

Info

SKU:BSS3003 ,UPC:

SKU: BSS3003

UPC: 632085030032

MPN: 3003-BSS

Info

SKU:
BSS3003
UPC:
632085030032
MPN:
3003-BSS

Description

Blue Sea 3000 500A Battery Selector 4 Position Switch with Alternator Field Disconnect

Model: 3003-BSS
  • Tin-plated copper studs for maximum conductivity and corrosion resistance
  • Accepts up to 4/0 AWG battery cables
  • Studs accepts 1/2" (M12) ring terminals
  • 7/8" (22mm) stud length accepts multiple cable terminals
  • Blue Sea Systems one-piece terminal stud design never loosens over time
  • Fits most Perko and Guest low amperage battery switch hole patterns
  • Case design allows surface, rear, or front panel mounting options
  • Tactile indicator conveys knob position by feel
  • Waterproof — rated IP66 from water projected in powerful jets
  • Ignition protected—safe for installation aboard gasoline powered boats
  • Make-before-break contact design allows switching between battery banks without power interruption
  • Includes AFD (Alternator Field Disconnect)
Specifications
Switch TypeSelector 4 Position
ColorGrey
Switch Positions4
Battery CombineYes
Alternator Field DisconnectYes
Maximum Voltage32V DC
Terminal Stud Torque220 in-lb (24.86 Nm)
Continuous Rating500A
Intermittent Rating700A (5 min)
Cranking Rating 30 sec1600A
Battery Inputs2
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Quantity to Meet RatingsTwo Cables / Terminal
Cable Size to Meet Ratings4/0 AWG (120mm )
Mounting HolesAccept 1/4" (M6) Screw
Terminal Stud Size1/2" (M12)
