B&G ZG100 GPS Antenna with Integrated Compass sensor
Model: 000-11048-002
- NMEA 2000 antenna module offers rugged and precise position, and heading sensor
- Spot-on, around-the-world accuracy -- supporting GPS and GLONASS, WASS/EGNOS/MSAS; Galileo-capable with future software update
- Excellent time-to-first-fix, multi-GNSS, high-speed updates — up to 10 times per second - for smoother and more accurate location updates
- Integrated rate stabilized compass to provide chart stabilization, accurate course over ground filtering at low speed, and radar overlay
- Rugged design for all marine environments and fully waterproof
- Include spat/pole mount for easy installation and flexible boat location for optimal performance
- Independent source selection on any display
The ZG100 GPS Antenna with Integrated Compass sensor providing Heading, Heel and Trim.
Note: Not suitable for MARPA or Steering of an Autopilot. Please use an Precision-9.
Specifications| General |
| Receiver | Type L1, C/A code, 1.575 GHz Frequency/L2 C/A code, 1.602 GHz Frequency |
| Channels | 32 channels |
| Position Update Rate | Up to 10 Hz (1,5,10) |
| Horizontal Accuracy | 3 m (9.8 ft) |
| Heading Accuracy | +/- 3° |
| Rate of Turn | +/- 3° |
| Pitch / Roll Accuracy | @30 degrees 1 grade error |
| Cold Start | 50 sec |
| Start-Up Time | 3 sec |
| Satellite Reacquisition | 5 sec |
| Environmental |
| Operating Temperature | -25° C to +60° C |
| Storage Temperature | -40° C to +85° C |
| Splash Proof | IPX7 |
| Humidity | 40° C, 93%RH, operating |
| Electrical |
| Input Voltage | 9 V DC - 18 V DC |
| Reverse Polarity Protection | Yes |
| Power Consumption | < than 2w |
| Current Consumption | < 100 mA @ 12 V DC |
| Dimensions | 90 mm (diam) x 38mm (height) 3.54" (diam) x 1.50" (height) |
| Weight | 0.14 Kg (0.3 lbs) aprox |
| Power/Data Cable | NMEA 2000 thru NMEA 2000 network |
| Antenna Connector | NMEA 2000 Micro C: Lowrance attached cable with Micro-C connector |
| Mounting | Flush mount / Standard Pole Mount |
| Communications |
| Data I/O Protocol | NMEA 2000 |
What's in the Box:- ZG100 GPS Antenna
- N2KEXT-6RD - 1.82 m (6-ft) NMEA 2000® cable
- N2K-T-RD - Micro-C T-connector
- Pole Mount
