Deluxe Pinion Depth Checker

The Deluxe Pinion Depth Checker is an essential precision tool designed for automotive technicians and performance enthusiasts who demand absolute accuracy when setting up differential ring and pinion gears. Achieving the correct pinion depth is critical for ensuring proper gear mesh, which directly impacts the longevity, noise levels, and strength of the drivetrain assembly. This comprehensive kit provides the necessary fixtures to eliminate guesswork, allowing you to establish a precise baseline for shim adjustments during a rebuild or gear ratio swap. By utilizing this professional-grade gauge, you ensure that every axle build meets or exceeds factory specifications for reliable performance.

This professional-grade tool features a high-accuracy dial indicator that measures the distance from the pinion gear face to the centerline of the carrier bearings. The Deluxe Pinion Depth Checker includes a variety of specialized fixtures and hubs engineered to interface seamlessly with a wide range of popular axle housings. By utilizing a bridge-style measurement system, the gauge provides stable and repeatable readings, ensuring that the critical tolerances required by high-performance applications are met with every installation.

Engineered for versatility, this kit is compatible with major differential platforms including GM, Dana, Ford, and Mopar axles, making it a staple for any shop specializing in drivetrain work. Whether you are performing a routine maintenance overhaul or building a custom rear end for racing, this tool ensures your gear set operates efficiently under heavy loads. Investing in the Deluxe Pinion Depth Checker allows you to complete your project with confidence, knowing you have the professional specifications required to prevent premature gear failure and excessive driveline noise.
