Paneltronics 'A' Frame Magnetic Circuit Breaker - 10 Amps - Single Pole

The Paneltronics 'A' Frame Magnetic Circuit Breaker—10 Amps, Single Pole (Part No. 206-071S)—is a standard branch AC or DC circuit breaker designed for use in Paneltronics electrical distribution panels. This magnetic circuit breaker meets all American Boat and Yacht Council (ABYC) standards for non-ignition-protected applications and carries UL 1077 recognition for U.S. use and CSA certification for Canadian installations, making it the preferred choice for marine electrical systems and off-grid power distribution where reliability and code compliance are non-negotiable.

The 10-amp single-pole configuration delivers branch protection in both AC and DC circuits, with trip-free operation (ABYC E-11.12.1.7.2.2) ensuring the breaker will interrupt current even if the handle is held in the ON position during an overload or fault condition. Manual reset design (ABYC E-11.12.1.7.2.4) requires deliberate operator intervention to restore power after a trip, preventing nuisance resets and providing diagnostic feedback that a fault has occurred. The compact 'A' frame form factor integrates seamlessly into standard Paneltronics panel slots without special mounting hardware or adapters.

This breaker is built for operators who demand ABYC-compliant electrical systems—marine vessel owners, off-grid energy installers, emergency response coordinators, and tactical teams relying on portable power distribution. The 10-amp rating protects low-draw circuits: cabin lighting, navigation systems, communications equipment, or specialized operational loads where individual branch protection is required. Users in salt-air or high-corrosion environments benefit from the robust design and magnetic trip mechanism, which responds consistently across temperature and environmental variance. Proper circuit-breaker protection is foundational to electrical safety; this unit delivers that protection without compromise.
